CIS 200mm Rapid Stainless Coupler

Product Code: 52022

In Stock

Description

Rapid Stainless Coupler

Brymec's high-quality cast-iron tube and fittings range offers a solution for soil, waste, and rainwater drainage. The Brymec lightweight, dry jointed pipework system is BBA certified, Kitemark certified and compliant with BS EN 877 which is the European standard for cast iron pipes and fittings. The full range consists of socketless cast iron tube and fittings jointed with either ductile iron or stainless steel rubber lined couplings.

Features and Benefits

  • Ready to use single piece coupling for rapid installation
  • Coupling provides electrical continuity though its radial grip
  • Stainless shell and screw for high corrosion resistance in aggressive environment
  • Quick installation time - Simple jointing method, no specialist tooling or training required
  • Pressure rated up to 0.5Bar < 200mm
Technical Data
TypeCouplers
BrandBrymec
ApprovalsBS EN 877 EN 681-1:1996
MaterialStainless Steel
Max PressureAxial Restraint up to 0.5 Bar

Downloadable Resources

View all resources

Resource Name

File Type

Options

Brymec Cast Iron Technical Manual

File Type

PDF

Cast Iron Rapid Coupler Technical Data Sheet

File Type

PDF
